Description
Rada 122 Urinal Sensor Mono Control
The Rada 122 Urinal Sensor Mono Control is a complete, automatic flushing system designed for a single urinal stall or individual wall-hung urinal. Its wall-mounted active infrared sensor detects the user and automatically activates the flush after use, providing hygienic, reliable and completely touch-free operation.
Programmable flush timing allows the system to be adjusted to suit the urinal and site requirements, helping control water usage while maintaining effective flushing. An automatic duty flush operates every 24 hours after use, helping prevent stagnant water, unpleasant odours and waste build-up during periods when the washroom is unoccupied.
The Rada Mono Control is a standalone system that controls one individual outlet. The kit includes the wall-mounted sensor, installation box containing the electronic control module and solenoid valve, inlet isolating ball valve, air gap, 12V AC transformer and 3 metres of sensor cable.
Key Features
- Touch-free automatic flushing for improved washroom hygiene
- Designed for one urinal stall or wall-hung urinal
- Adjustable flush duration from approximately 3 to 10 seconds
- Optional two-second pre-flush setting
- Automatic 24-hour duty flush
- Sensor detection range of up to 550mm
- Safe 12V AC operating system
- Solenoid operating pressure range of 20–1000kPa
- Chrome-plated, vandal-resistant wall sensor with a shatterproof sensing window
- Supplied with an isolating valve for easier servicing and maintenance
Kit Includes
- Rada 122 wall-mounted infrared sensor
- Electronic control module
- ½-inch BSP male solenoid valve
- Inlet isolating ball valve
- Urinal air gap
- 12V AC transformer
- 3-metre sensor cable
Specifications
Product number: 850911
Application: Single urinal stall
Sensor range: 0–550mm
Operating pressure: 20–1000kPa
Power supply: 12V AC
Sensor dimensions: 84mm high × 68mm wide × 22mm deep
WELS rating: 4 Stars – 1.4 litres per flush
Approval: ATS 5200.020
The Rada 122 Mono Control is ideal for commercial bathrooms, schools, offices, sporting facilities, hospitality venues and other public washrooms requiring dependable, water-efficient automatic urinal flushing.
